Surly Grappler Gravel Bike 2024

A Dedicated Drop-Bar trail bike built for bikepacking excursions, singletrack sessions, and all-day dirt ride.

The Grappler is our dedicated drop-bar trail bike.  Building off the customized setups we've see nriders experimenting with over the years, it captures a more confident, nimble, and reactive off-road/drop-bar experience.  Engineered first and foremost around a comfortable, stable drop-bar hand position, it offers trail ready geo and impressive tire clearance for lively all-day rides on a single track, double track, and gravel, as well as a full assortment of mounts for bikepacking excursions.

• Frame  -  100% Chromoly Steel frame, Natch Tubing, double-butted main triangle, TIG welded, E.D. Coated
• Fork  -  100% Chromoly steel fork, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
• Brakes  -  Tektro Mira MD-C400
• Rotors  -  Tektro Light Wave 180/160
• Headset  -  Cane Creek 40
• Stem  -  Promax DA-296, 31.8
• Handlebar  -  Salsa Cowchipper 31.8
• Seatpost  -  TransX YSP15, 20.9, 100mm travel
• Saddle  -  WTB Volt 142
• Crankset  -  Samox 2PCS Boost 32t
• Bottom Bracket  -  Samox BSA 24
• Rear Derailleur  -  Microshift M6205
• Cog or Cogset  -  Microshift 11-48t
• Shifters  -  Microshift SB-M100, AdventX Dual Control Levers
• Chain  -  KMC X10
• Rims  -  WTB ST i40 TCS
• Front Hub  -  Novatec 15x110mm, 32h
• Rear Hub  -  Novatec 12x148mm, 32h
• Tires  -  Teravail Ehline, 27.5 x 2.5", 60tpi
• Grip/Tape  -  Cork Black
